ROBIN® Top-entry and Bottom-entry Mixer
Milton Roy Mixing’s customized top-entry and bottom-entry mixers for optimized efficiency
ROBIN top-entry and bottom-entry agitators are custom-made and perfectly attuned to meet the specific characteristics of complex processes in extreme conditions.
Manufactured to ATEX certification standards, our expert industrial mixing engineers will work with you to understand the processes and constraints to design a ROBIN agitator specific to your application requirements. By using computational fluid dynamics (CFD) tools, your ROBIN agitator will be designed to ensure maximum results and long-term financial benefits.
You’ll benefit from a worldwide knowledge and financial base of high-value projects.
We offer 4 different models to ensure a customized fit for your project.
Model A5
For use in an open tank at atmospheric pressure.
- Rotation speed: 10 to 500 rpm
- Rated power: about 0.55 to 500 kW
- Impeller diameter: 0.20 to 6 m
- Impeller type: all kind
- Construction material: all machinable metallic material
- Pressure use: atmospheric pressure
- Temperature up to 500°C (932°F)
- Pressure with vaccum at 300 gauge bars
- Viscosity up to 1000 Pas
Model B5
For use when a simple tightness is required to avoid contact between the product and the atmosphere (mixing under few mbars of pressure or vacuum or when the product is dangerous or must be kept under inert atmosphere)
- Rated power: about 0.55 to 37 kW
- Rotation speed: 500 to 10 rpm
- Impeller diameter: 0.20 to 6m
- Impeller type: all kind
- Construction material: machinable metallic material
- Pressure use: few mbar difference with the atmospheric
Model E5
For use in mixing at atmospheric pressure in open tanks
- Rated power: about 0.75 to 250 kW
- Rotation speed: 500 to 10 rpm
- Impeller diameter: 0.50 to 6m
- Impeller type: all kind
- Construction material: all machinable metallic material
- Pressure use: few mbar difference of the atmospheric pressure
Model F5
For use in all operations processed under pressure or vacuum, or mixing dangerous substances.
- Rated power: about 0.75 to 250 kW
- Rotation speed: 500 to 10 rpm
- Impeller diameter: 0.25 to 6m
- Impeller type: all kind
- Construction material: all machinable metallic material
- Pressure use: full vacuum to approx. 75 Bg (250 Bg with magnetic drive)
