GSPX – General Service Petroleum BB5 API 685
The GSPX sealless magnetic drive pump from HMD Kontro is a multi-stage leak-free pump for safe and efficient high-differential processing.
It uses proven magnetic drive technology and produces higher differential pressure than single-stage sealless models.
The pump is built to API 685 specifications and is suitable for petrochemical processing, petroleum production and refining, offshore and chemical processing applications complying with all industry specifications. The GSP is typically used in toxic, aggressive, hot, crystallising and high value processes.
Its sealless design delivers total product containment and its interchangeable components and commonality with the GSP pump range maximise convenience and reduce spare parts holding.
The GSPX delivers in terms of space, costs and servicing when compared with standard single stage pumps. It has high head performance in a compact sealless magnetic drive package providing more safety and efficiency and maximum uptime. It also has an optimised diffuser design and optional ZeroLoss® composite containment shell and thus eliminates coupling losses and heating of the process liquid.
US 60 Hz
| Item | Details |
|---|---|
| Heads to | 1400 ft |
| Flows to | 450 gpm |
| Maximum Motor Power | 535 HP |
| Temperature Range | -40 to 500°F |
| Maximum Case Working Pressure | 725 psi |
| Hydrotest Pressure | 1088 psi |
| Maximum Viscosity | 200 csT |
| Motor Details | Industry standard |
| Solids Range | Maximum of 5% w/w up to 150 microns |
| Mounting Configuration | Long coupled |
| Dimensional Standards | N/A |
| Number of Available Hydraulics | 4 |
| Available Flanges | ANSI 150lb / 300lb RF |
Metric 50 Hz
| Item | Details |
|---|---|
| Heads to | 295 m |
| Flows to | 85 m3/hr |
| Maximum Motor Power | 400 kW |
| Temperature Range | -40 to 260°C |
| Maximum Case Working Pressure | 50 Bar |
| Hydrotest Pressure | 75 Bar |
| Maximum Viscosity | 200 csT |
| Motor Details | Industry standard |
| Solids Range | Maximum of 5% w/w up to 150 microns |
| Mounting Configuration | Long coupled |
| Dimensional Standards | N/A |
| Number of Available Hydraulics | 4 |
| Available Flanges | ANSI 150lb / 300lb RF |
Benefits of the HMD Kontro GSPX Pump:
- Multiple inline stages in an end-suction configuration
- Compact package and easy plant installation
- BB5 barrel style design
- API compliant with no tie bolts
- Interchangeable parts
- Based on the proven Frame 2 magnetic drive pump
- 2 or 3 stage options available
- Two diffuser based hydraulic options
The GSPX pump is a multi-stage derivative of the established HMD GSP range using a between bearings design (BB5) for the second and third stage impellers.
| Item | Details |
|---|---|
| Flows to | 85 m³/hr (450 gpm) |
| Heads to | 295 m (1400 ft) |
| Pressure | 40 bar / 580 psi |
| Temperature Range | -40 to 260°C (-40 to 500°F) |
