Pneumatic Positioner
Same series as EP800 but this works having pneumatic signal (20 to 100Kpa
Same series as EP800 but this works having pneumatic signal (20 to 100Kpa). Also double acting and single acting types are available.
Specifications
| Col1 | Col2 | Col3 | |
|---|---|---|---|
| Type | PPA800 for single acting | PPC800 for Double acting | |
| Application | Linear-motion Valve/Rotary-motion Valve/Long-stroke Valve | #colspan# | |
| Input Signal | 20-100,20-60,60-100kPa | #colspan# | |
| Air supply | 140-700kPa | #colspan# | |
| Single acting type | Double acting type | ||
| Linearity | +/-1.0% | +/-1.5% | |
| Hysteresis | 0.5% | 0.8% | |
| Response Level | 0.1% | 0.2% | |
| Repeatability | 0.2% | 0.3% | |
| Air consumption | 5Nl/min. at sup.140kPa | 15Nl/min. at sup.400kPa | |
| Max. capacity | 175Nl/min. at sup.140kPa | 400Nl/min. at sup.400kPa | |
| Enclosure | Weather proof | #colspan# | |
| Environment temp. | Standard:-20 - 80/ Low temp.:-50 - 60/ High temp.:0 to 100 deg.C | #colspan# | |
